Ship parts 170 Series QCJK-I/WX Marine Monitor
Author:Chong Qing Shu Yang Trading Company | Release time:2015/11/10 12:05:07 | Click:1581
Ship parts 170 Series QCJK-I/WX Marine Monitor
Power supply: 24VDC
Working environment: A. working environment temperature: -10 ℃ ~ +55 ℃; B. relative humidity: ≤ 98%;
C.: vibration: 2 ~ 13.2Hz, the vibration amplitude of ± 1.6mm; 13.2 ~ 80Hz, acceleration ± 6.9m/s ²;
Display: four digital tube display.
Protection: IP44
Basic function: can realize the diesel engine speed, oil pressure, water temperature, oil temperature and other parameters of the real-time monitoring; the line parameters of the alarm or shutdown, fuel leakage alarm function; normal running time of diesel engine automatic accumulation; according to the user request parameters can be modified online.
Main distribution models: high speed diesel 135 series, 226B series, WD615 series, 170 series, 160 series, 190 series of medium and small power machine parameters monitoring.
Installation way: Machine or airborne installation
